USA Lab UltraChill 11.9 Cu Ft -86C Upright Ultra-Low Freezer- Touch Screen -80°C ULT
Reference: UCF-11.9-86
Manufacturer: USA Lab
UltraChill 11.9 Cu Ft -86°C Upright Ultra-Low Freezer – Touch Screen | USA Lab Introducing our UltraChill 11.9 Cu Ft -86°C Upright Ultra-Low Freezer — the ultimate solution for long-term storage of sensitive biologicals, vaccines, enzymes, and research…
In stock
Payment Providers
More info
UltraChill 11.9 Cu Ft -86°C Upright Ultra-Low Freezer – Touch Screen | USA Lab
Introducing our UltraChill 11.9 Cu Ft -86°C Upright Ultra-Low Freezer — the ultimate solution for long-term storage of sensitive biologicals, vaccines, enzymes, and research specimens. Built with a microprocessor control system and a responsive 7″ LCD touch screen, UltraChill delivers precise temperature stability, robust protection, and efficient operation for mission-critical labs.
With a wide operating range of –40°C to –86°C, advanced cascade refrigeration, and optimized airflow, the UltraChill series maintains exceptional temperature uniformity across the cabinet to safeguard every sample.
Engineered for low power use and reliability, it features high-density insulation, SECOP compressors, and comprehensive alarm monitoring to ensure peace of mind 24/7.
Why this ultra-low freezer?
- Wide ULT range — holds setpoints from –40°C to –86°C for enzymes, vaccines, and long-term biobanking.
- Robust construction — SUS304 interior, foamed inner doors, and color-sprayed steel exterior built for heavy daily use.
- Comprehensive alarms — power, high/low temp, door ajar, sensor error, low battery, and more with 72h backup.
- Organization ready — 12 rack positions (4×4), 192 two-inch boxes, up to 19,200 × 2 ml vials.
- Serviceable design — SECOP dual-compressor cascade system with accessible components.
Technical Specifications
| Category | Details |
|---|---|
| Basic | |
| Cooling method | Direct Cooling |
| Defrost | Manual |
| Temperature range | –40°C ~ –86°C |
| Ambient temperature | 10 ~ 32°C |
| Display | 7" LCD touch screen |
| Access port QTY/Dia. | 1 / 25 mm |
| USB Access | Y |
| Remote alarm access | RS232/485 |
| Outside material | Color sprayed steel |
| Inside material | SUS304 |
| Castor | Universal |
| Refrigeration System | |
| Refrigerant | HC (R290 & R170) |
| Temp. controller | Microprocessor |
| System | Cascade system |
| Sensor | PTC |
| Compressor brand/QTY | SECOP / 2 |
| Capacity (L / cu.ft) | 338 / 11.93 |
| Insulation | PURF |
| Inner door material / QTY | Foamed SUS304 / 2 |
| Racks | 12 (4×4) |
| Boxes (2 inches) | 192 |
| Samples (2 ml) | 19,200 |
| Alarms | |
| High / low temperature | Y |
| Power failure | Y |
| Abnormal voltage | Y |
| Sensor error | Y |
| Door ajar | Y |
| Filter screen check | Y |
| Thermostat failure | Y |
| Low battery | Y |
| Condenser clean | Y |
| High ambient temperature | Y |
| Power failure backup (alarm) | 72 h |
| Electrical Data | |
| Voltage frequency (V/Hz) | 110V/120V 60Hz |
| Power (W) | 620 W |
| Current (A) | 7.93 A |
| Power consumption | 11.17 Wh/24h |
| Noise (db) | 50 |
| Dimensions | |
| Package size (W×D×H) (in) | 36.8" × 42" × 84" |
| Exterior size (W×D×H) (in) | 33.6" × 42.2" × 75" |
| Interior size (W×D×H) (in) | 19.2" × 24" × 45" |
| Weight (lb) | 540 |
| Shipping weight (lb) | 680 |
| Accessories | |
| Chart recorder | Optional |
| Data logger | Y |
| CO2 back-up system | Optional |
| LN2 back-up system | Optional |
| Gloves | Optional |
FAQ
What is the operating range of this ULT freezer?The UltraChill series holds setpoints from –40°C to –86°C, ideal for long-term preservation of sensitive samples.
Integrated alarms include power failure notifications and a 72 hour backup for the alarm system (battery), prompting rapid response procedures.
The cabinet supports 12 racks (4×4), up to 192 x 2" boxes, totaling approximately 19,200 × 2 ml vials.
Keep condenser surfaces clean, verify door gaskets, and periodically test alarms and probes. The microprocessor interface provides prompts for filter and sensor checks.
All items are carefully packaged to ensure safe delivery. In the rare event that your item arrives damaged, please notify us within 3 days of receipt. We will promptly provide a replacement or issue a refund.
Please note that any damage occurring after delivery is not covered under warranty. We appreciate your understanding and your trust in our products.
Specifications
| Power | 110V/120V 60Hz |
| Noise | 53 dba |
| Temp Range | -40℃～-86℃ |
| Capacity(L/cu.ft) | 338/11.93 |
| Weight | 540 lbs |
| Internal Dimensions (WxDxH) | 19.2" x 24" x 45" |
| External Dimensions (WxDxH) | 33.6" x 42.2" x 75" |
| Certification | CE |
| Warranty Term | 1 Year |
