6 CFM 2 Stage Ignition Proof Vacuum Pump

Key Features:

• Single voltage operation 115V 60Hz
• Exceptional ultimate vacuum rating as low as 10 microns
• Advanced air cooled motor design for operation in high ambiet temperatures
• Proprietary oil mist free exhaust port cap for clean, safe job environment
• Multiple port connections for 1/4, 3/8, and 1/2 ACME
• Easy maintenance with large oil sight glass and fill port with easily accessible oil drain port.
• Solid rubber base provides extreme shock resistance
• Sure grip handle ergonomically designed for superior comfort and portability
• 1/4"" Flare adapter is not included.

Specifications:

• Stage: 2
• Motor Size (HP) RPM @ 60Hz: 1/2 (HP)2880/3440
• Dimensions (Inches): 13.1 x 5.5 x 10
• Weight: 22.5 lb / 14.0 kg
• Operating Temperature Range: 0C (32F) to 52C (125F)
• Power Source: 115V 60Hz
• Ultimate Vacuum: as low as 10 Microns
• Oil Capacity: 16 oz / 470 ml
• Construction: Heavy Gauge Aluminum Chasis with hard rubber base and rubber lined steel handle
• Overload Protection: Motor Thermally Protected, Dual Voltage units have extra IEC fuse
• Control System: ON-OFF power switch
• Free Air Displacement: 6 CFM @ 60Hz
• Intake Fittings: 1/4, 3/8, and 1/2 ACME

Certification and Refrigerant Compatibility

• Designed and tested to meet ANSI 12:12.01 ignition-proof standards, with a sealed start relay and an ignition-proof ON/OFF switch.

• Safe for Class A1 (non-flammable), A2L (low flammability), A2 and A3 (flammable) refrigerants, and ammonia (NH3). The steel multi-port inlet connections are ammonia compatible.

• Gas ballast valve, managing moisture to reach a deeper vacuum.

• 10 ft hard-wired power cord.
