USA Lab High Efficiency Powder Fume Hood
Reference:
Manufacturer: USA Lab
High Efficiency Powder Containment Hood | USA Lab The High Efficiency Powder Containment Hood combines powerful airflow with a sturdy, compact enclosure to deliver reliable respiratory and environmental protection during powder handling. Engineered to pull…
In stock
Customize your product
Payment Providers
More info
High Efficiency Powder Containment Hood | USA Lab
The High Efficiency Powder Containment Hood combines powerful airflow with a sturdy, compact enclosure to deliver reliable respiratory and environmental protection during powder handling. Engineered to pull harmful particulate up and away from the operator’s breathing zone, it captures airborne contaminants into a dedicated filter chamber to help keep work areas cleaner and safer.
Depending on your application, the filter chamber can be configured with HEPA filtration (up to 99.97% efficient at 0.3 microns and larger), ULPA filtration (up to 99.9995% efficient at 0.12 microns and larger), Activated Carbon, or specialty-blended media (including Acid Gas, Mercury, Aldehyde, and Ammonia blends) for targeted adsorption.
With quiet operation, long filter life, and fast, simple filter changes, this containment hood is built for daily lab and production workflows where powder control and operator protection matter most.
Why this high efficiency powder containment hood?
- Built for powder control — helps capture airborne particulate at the source before it spreads into the room.
- Configurable filtration — choose HEPA, ULPA, activated carbon, or specialty media based on the hazard and process needs.
- Operator-focused design — engineered airflow draws particulate up and away from the breathing zone during weighing, dispensing, and transfer.
- Quiet and efficient — designed for low-noise operation while maintaining effective containment performance.
- Fast maintenance — simple filter change process supports uptime and long filter life in routine operation.
Technical Specifications
| Model | 24" Wide | 30" Wide | 40" Wide | 50" Wide |
|---|---|---|---|---|
| OD Dimensions | 24"D x 26"W x 25"H | 24"D x 32"W x 25"H | 24"D x 42"W x 25"H | 24"D x 52"W x 25"H |
| ID Dimensions | 23.5"D x 24"W x 24"H | 23.5"D x 30"W x 24"H | 23.5"D x 40"W x 24"H | 23.5"D x 50"W x 24"H |
| Hood Materials | Sides: .250" White Acrylic | Base: .500" HDPE | Top: .500" Clear Polycarbonate | Sides: .250" White Acrylic | Base: .500" HDPE | Top: .500" Clear Polycarbonate | Sides: .250" White Acrylic | Base: .500" HDPE | Top: .500" Clear Polycarbonate | Sides: .250" White Acrylic | Base: .500" HDPE | Top: .500" Clear Polycarbonate |
| Front Window | 0.250" Clear Polycarbonate | 0.250" Clear Polycarbonate | 0.250" Clear Polycarbonate | 0.250" Clear Polycarbonate |
| Blower Dimensions | 13" L x 13" W x 17" H | 13" L x 13" W x 17" H | 13" L x 13" W x 17" H | 13" L x 13" W x 17" H |
| Motor | Fractional Horsepower | Fractional Horsepower | Fractional Horsepower | Fractional Horsepower |
| Weight | 125 lbs | 125 lbs | 100 lbs | 125 lbs |
| Filter Efficiencies | HEPA 99.97% @0.3µ | ASHRAE 95% @0.5µ | ULPA 99.9995% @0.12µ | Carbon/Specialty | HEPA 99.97% @0.3µ | ASHRAE 95% @0.5µ | ULPA 99.9995% @0.12µ | Carbon/Specialty | HEPA 99.97% @0.3µ | ASHRAE 95% @0.5µ | ULPA 99.9995% @0.12µ | Carbon/Specialty | HEPA 99.97% @0.3µ | ASHRAE 95% @0.5µ | ULPA 99.9995% @0.12µ | Carbon/Specialty |
| Inlet Velocity Note | 50" Hood = 92 FPM | 50" Hood = 92 FPM | 30" Hood = 153 FPM | 50" Hood = 92 FPM |
| Electrical | 115/1/60 2A | 220/1/50 .75A | 115/1/60 2A | 220/1/50 .75A | 115/1/60 2A | 220/1/50 .75A | 115/1/60 2A | 220/1/50 .75A |
| Sound Level | 61–66 dBA | 61–66 dBA | 61–66 dBA | 61–66 dBA |
| Max Operating Temp | ≤170°F | ≤170°F | ≤170°F | ≤170°F |
| Warranty | Limited 2-year | Limited 2-year | Limited 2-year | Limited 2-year |
FAQ
What is the High Efficiency Powder Containment Hood used for?The High Efficiency Powder Containment Hood is designed to help control airborne particulate during powder handling tasks such as weighing, dispensing, and transfer. It pulls harmful particulate up and away from the operator’s breathing zone and captures it in a filter chamber to support respiratory and environmental protection.
The High Efficiency Powder Containment Hood can be configured with HEPA filtration (up to 99.97% at 0.3 microns and larger), ULPA filtration (up to 99.9995% at 0.12 microns and larger), Activated Carbon, or specialty-blended media such as Acid Gas, Mercury, Aldehyde, and Ammonia blends depending on the application.
Yes. The High Efficiency Powder Containment Hood includes a fluorescent light and a variable speed controller (115V only) to help dial in airflow for your process.
A velometer is included with the High Efficiency Powder Containment Hood to support airflow verification and routine checks as part of your SOPs.
All items are carefully packaged to ensure safe delivery. In the rare event that your item arrives damaged, please notify us within 3 days of receipt. We will promptly provide a replacement or issue a refund.
Please note that any damage occurring after delivery is not covered under warranty. We appreciate your understanding and your trust in our products.
