PolyScience AD 7 Liter 200°C Max Heated Circulator - 208V
Reference: AD07H200-A13D
Manufacturer: PolyScience
Detail specs on PolyScience's website
In stock
Optional Must Have Accessories
|
Calflo Heat Transfer Fluid 316°C (600°F) - 5 Gallon Pail (18.9 L) | +CAD $375.00 |
Payment Providers
Standard Package
| PolyScience AD 7 Liter 200°C Max Heated Circulator - 208V | 1 pc |
| Power Cord | 1 pc |
| Packing Kit (Plastic Bag Containing Manual, Warnings and Quickstart Guide) | 1 pc |
| Fitting Kit (See Below for Contents) | 1 pc |
| ¼” MNPT x 3/8” Barb | 2 pc |
| ¼” MNPT x ¼” Barb | 2 pc |
| ¼” MNPT x 3/16” Barb (110V & 220V) | 1 pc |
| ¼” MNPT to M16 (220V only) | 1 pc |
| Hose Clamps | 4 pc |
Overview
The PolyScience AD 7 litre heated circulator controls a bath from 10 °C above room temperature up to 200 °C, with temperature stability of ±0.01 °C. The 7 L stainless steel reservoir comes with a cover.
Its pump both pushes and pulls, so it can circulate fluid through an external closed loop, such as a reactor jacket, and return it to the bath. The controller head swivels 180 degrees for easy viewing and has a touch-pad LCD that reads to 0.01 degrees.
For automation it offers USB, Ethernet and RS-232/RS-485 connections and accepts an external temperature probe, so you can control from the sample instead of the bath. Fittings and hose clamps are in the box, as listed above.
Key features
- Ambient +10 °C to 200 °C working range
- ±0.01 °C temperature stability
- 7 L stainless steel reservoir with cover
- Pressure/suction pump for external closed loops
- Swivel 180 rotating controller with touch-pad LCD
- USB, Ethernet and RS-232/RS-485
- External temperature probe input
Delivery and pickup
- Ships across Canada and to the USA by Purolator, UPS or FedEx - live rates at checkout.
- Free pickup in Langley, BC.
- We deliver orders of $1000 or more in the Lower Mainland and Fraser Valley ourselves.
Questions
Can it run an external closed loop?
Yes. The pressure/suction pump pushes fluid out and draws it back to the bath.
How high can it go?
Up to 200 °C. The low end is 10 °C above room temperature, since it has no refrigeration.
Can I control it from a computer?
Yes. It has USB, Ethernet and RS-232/RS-485 ports.
| Temperature range | Ambient +10 °C to 200 °C |
| Stability | ±0.01 °C |
| Reservoir | 7 L, stainless steel, with cover |
| Pump | Pressure/suction |
| Display | 3.75 in touch-pad LCD, 0.01 resolution |
| Communication | USB, Ethernet, RS-232/RS-485 |
| Bath opening | 15.7 x 14.2 x 12.7 cm |
