Ethylene Glycol Inhibited Industrial Grade -50c | +CAD $272.81 |
-80 50L Capacity 50L/M Plate Chiller - Science King
Reference:
Manufacturer: Science King
The Science King -80 50L capacity recirculating plate chiller offers 4200 watts of cooling, working temperature range of -80C-RT dynamic, reliable, and efficient; these powerful, compact chillers offer full-range cooling capabilities for quick power-up and cool-down of your application.
In stock
Optional Must Have Accessories
|
3/8" Reinforced Food Grade Vacuum Chilling Tubing -60C to +135C | +CAD $48.63 |
Customize your product
Payment Providers
Coolant temperature: －80℃-RT
Reservoir: 50L
Flow: 50L/min
Lift: 6m
Refrigerant: R404
Refrigerating Capacity: 1000-4900W
Rated Power: 4200W
Power supply: 220V single phase (3 phase available on request)
Environment temperature: 5~35℃
Dimensions(mm): 740*780*1160
Weight(kg): 410kg
Overview
This Science King recirculating chiller holds 50 L of coolant and pumps it out at up to 50 L/min to your equipment, such as a reactor jacket, condenser or cold trap, then takes it back to be cooled again. Its working range is -80 °C up to room temperature.
This is the plate model; a coil model is also listed. Science King is our own brand, built in our own factory.
Key features
- Working range -80 °C to room temperature
- 50 L coolant reservoir
- Circulation up to 50 L/min
- Pump lift 6 m
- Refrigerating capacity 1000-4900 W
- Rated power 4200 W
- 220V single phase (3 phase available on request)
Delivery and pickup
- Freight: shipping is quoted after you order (heavy item).
- Free pickup in Langley, BC.
- Liftgate delivery can be added at checkout for $77.53 if you have no loading dock.
- We deliver orders of $1000 or more in the Lower Mainland and Fraser Valley ourselves.
Questions
How cold does it go?
Down to -80 °C. The working range is -80 °C to room temperature.
What power does it need?
220V single phase (3 phase available on request).
Where can it be installed?
Indoors, in a room kept between 5 and 35 °C. It ships by freight, quoted after you order, or you can pick it up free in Langley, BC.
| Working range | -80 °C to room temperature |
| Reservoir | 50 L |
| Flow | 50 L/min |
| Pump lift | 6 m |
| Refrigerating capacity | 1000-4900 W |
| Refrigerant | R404 |
| Rated power | 4200 W |
| Power supply | 220V single phase (3 phase available on request) |
| Ambient temperature | 5 to 35 °C |
| Dimensions | 740 x 780 x 1160 mm |
| Weight | 410 kg |
