2L Air-Tight Volumetric Powder Feeder with Built-in Agitator & Stainless Steel Hopper
Reference: AI-2L-Feeder
Manufacturer: Across International
The AI-2L-Feeder is an air-tight automatic volumetric powder feeder designed for continuous, controlled delivery of solid powder into tube or rotary furnaces during firing and heat treatment processes. A motor-driven agitator combined with a built-in vibrator conditions the material to a uniform bulk density, ensuring consistent fill of the feed screw flights and preventing rat-holing, bridging, clogging, and material buildup.
In stock
Payment Providers
Features
- Stainless steel hopper with integrated vibrator for consistent powder flow
- Feed rate continuously adjustable via potentiometer knob: 0–97 ml/min
- KF25 material delivery port for direct furnace connection
- Torque value: 4.45 N·m
- Maximum operating pressure: 1 psig
Power
- Input: Single Phase 208–240 VAC, 200W max
- Motor drive: 24 VDC
Dimensions: Hopper capacity: 2 liters
Overview
The AI-2L-Feeder meters solid powder into a tube or rotary furnace at a steady, adjustable rate while the furnace is firing or heat treating. It is sealed against the outside air, so the furnace atmosphere is not disturbed while you feed.
Powder that bridges or packs down will feed unevenly. To stop that, a motor-driven agitator and a vibrator on the hopper keep the material loose and at an even density, so the feed screw fills the same way every turn. You set the rate with a single knob, anywhere from 0 to 97 ml per minute.
Key features
- 2 litre stainless steel hopper
- Motor-driven agitator plus built-in vibrator
- Feed rate adjustable by knob, 0 to 97 ml/min
- Air-tight design for controlled-atmosphere furnaces
- KF25 delivery port
- Rated for a maximum operating pressure of 1 psig
Compatible with
Tube furnaces and rotary furnaces with a KF25 inlet.
Delivery and pickup
- Ships across Canada and to the USA by Purolator, UPS or FedEx - live rates at checkout.
- Free pickup in Langley, BC.
- Liftgate delivery can be added at checkout for $77.53 if you have no loading dock.
- We deliver orders of $1000 or more in the Lower Mainland and Fraser Valley ourselves.
Questions
Can I run it on a 120 V outlet?
It is rated for single-phase 208 to 240 V AC input (200 W maximum). The motor itself runs on 24 V DC.
How do I set the feed rate?
Turn the potentiometer knob. The rate is continuously adjustable from 0 to 97 ml/min.
How does it connect to my furnace?
Through a KF25 delivery port.
| Hopper | 2 L, stainless steel |
| Feed rate | 0 to 97 ml/min, adjustable |
| Outlet | KF25 |
| Torque | 4.45 N·m |
| Max. operating pressure | 1 psig |
| Input power | 208-240 V AC, single phase, 200 W max |
| Motor drive | 24 V DC |
