USA Lab Hotplate Stirrer 380 - 5L - TUV Certified
Reference: USA-H380-PRO
Manufacturer: USA Lab
USA Lab H380 Digital Magnetic Hotplate Stirrer | 5.5" Plate, 380°C Max | TUV Certified The USA Lab H380 is a technically advanced digital magnetic hotplate stirrer designed for chemical synthesis, analytical laboratories, biopharma workflows, sample…
In stock
Payment Providers
More info
USA Lab H380 Digital Magnetic Hotplate Stirrer | 5.5" Plate, 380°C Max | TUV Certified
The USA Lab H380 is a technically advanced digital magnetic hotplate stirrer designed for chemical synthesis, analytical laboratories, biopharma workflows, sample preparation, and general laboratory mixing. Independent back-lit LCDs provide clear control of heating and stirring functions, while PID temperature regulation delivers precise heating performance.
A 5.5" × 5.5" glass-ceramic work surface provides excellent chemical resistance and efficient heat transfer with temperatures up to 380°C. The brushless DC motor delivers smooth, stable torque with stirring speeds up to 1,500 rpm for volumes up to 5 L of water.
The USA Lab H380 supports external PT1000 temperature feedback with ±0.5°C sensor accuracy for tighter process control. Built-in over-temperature protection limits heating at 420°C, while the persistent "HOT" indicator warns users when the plate remains above 50°C. Probe and stand are included.
Why the USA Lab H380 Hotplate Stirrer?
- Precise digital control — independent back-lit LCDs provide clear heating and stirring control for repeatable laboratory operation.
- PID temperature stability — temperature regulation maintains control to ±1°C and supports PT1000 external feedback with ±0.5°C sensor accuracy.
- Powerful brushless mixing — maintenance-free brushless DC motor provides smooth torque and stirring speeds up to 1,500 rpm.
- Chemically resistant work surface — 5.5" × 5.5" glass-ceramic plate supports rapid heat transfer and operation up to 380°C.
- Integrated safety protection — 420°C over-temperature protection and persistent "HOT" indication above 50°C help improve operating safety.
Technical Specifications
| Specification | Details |
|---|---|
| Model | USA Lab H380 |
| Product Type | Digital Magnetic Hotplate Stirrer |
| Work Plate Dimension | 140 mm × 140 mm | 5.5" × 5.5" |
| Work Plate Material | Glass Ceramic with aluminum cover base |
| Motor Type | Brushless DC motor |
| Power | 510 W |
| Heating Output | 500 W |
| Voltage | 100–120 V / 60 Hz |
| Stirring Positions | 1 |
| Maximum Stirring Volume [H2O] | 5 L |
| Maximum Magnetic Bar Length | 50 mm |
| Speed Range | 200–1,500 rpm |
| Display Type | LCD |
| Heating Temperature Range | Ambient +5°C to 380°C |
| Overheat Protection | 420°C |
| Temperature Display Accuracy | ±1°C |
| External Temperature Sensor | PT1000, accuracy ±0.5°C |
| Control Accuracy of Sensor | ±20 rpm |
| Dimensions [W × D × H] | 320 × 180 × 108 mm | 12.6 × 7 × 4.25" |
FAQ
What is the maximum temperature of the USA Lab H380 hotplate stirrer?The USA Lab H380 provides a heating temperature range from ambient +5°C up to 380°C, with PID temperature control for precise and repeatable heating.
The USA Lab H380 offers adjustable magnetic stirring from 200 to 1,500 rpm and supports stirring volumes up to 5 L of water.
Yes. The USA Lab H380 supports an external PT1000 temperature sensor with an accuracy of ±0.5°C for tighter temperature feedback and control. The probe and stand are included.
The USA Lab H380 includes 420°C over-temperature protection and a persistent "HOT" indicator when the work surface remains above 50°C, helping alert users to residual heat.
All items are carefully packaged to ensure safe delivery. In the rare event that your item arrives damaged, please notify us within 3 days of receipt. We will promptly provide a replacement or issue a refund.
Please note that any damage occurring after delivery is not covered under warranty. We appreciate your understanding and your trust in our products.
Specifications
| Brand | USA Lab |
| Work Plate Dimensions | 135 x 135mm | 5" x 5" |
| Max. Stirring Volume | 5L |
| Speed Range | 200 - 1500rpm |
| Voltage | 100 - 120V 60Hz |
| Dimension [W x D x H] | 150×260×80mm | 6 x 10.2 x 3.14 " |
| Warranty Term | 1 Year |
